A solar attic fan wattage comparison should match each panel rating to documented airflow, coverage, controls, solar exposure, and mounting requirements rather than treating wattage as a standalone performance score.
Become an authorized The Attic Depot dealer for contractor-focused product guidance, technical support, training, and dealer resources.
Short answer: The current The Attic Depot documentation verifies 25W, 30W, and 70W solar attic fan models, but it does not verify 40W or 60W models. The documented 25W roof-mount fan is rated up to 1,365 CFM for attics up to 1,300 square feet. The documented 30W roof-mount and gable-mount fans are rated up to 1,550 CFM for applications around 1,500 square feet. The documented 70W roof-mount fan is rated up to 3,850 CFM for applications up to 2,500 square feet. Confirm current product submittals before quoting any model or specification.
For additional contractor context, review the attic performance products contractor guide. Then use the solar attic fan product range to compare the model-specific details that apply to the project in front of you.
What Wattage Means in a Solar Attic Fan Comparison
Panel wattage describes the solar panel's rated electrical input capacity under specified conditions. It does not convert directly to CFM, coverage area, or installed performance. A larger number may indicate more available input capacity, but the fan motor, panel orientation, shading, controls, ventilation balance, and mounting location also affect the application.
CFM, or cubic feet per minute, is the model's rated air-moving capacity. The documented 25W and 30W figures in this comparison are model-specific claims, not a universal watts-to-CFM formula. Contractors should use the current documentation for the exact fan being proposed and avoid assigning a CFM value to an undocumented wattage.
Review the full installation context
- Attic size: Compare the measured or confirmed attic area with the model's stated coverage.
- Solar exposure: Check roof orientation, shading, panel angle, and the hours of useful sun.
- Intake ventilation: Confirm that soffit, gable, ridge, or other intake paths can support the exhaust plan. A larger fan cannot correct blocked or inadequate intake ventilation.
- Mounting location: Decide whether the project supports roof mounting, gable mounting, or another documented configuration.
- Controls: Match thermostat-only operation or thermostat-and-humidistat operation to the project's needs.
- Project documentation: Confirm current submittals, windstorm documentation, and other local requirements for the exact model and installation.
25W vs. 30W Solar Attic Fan Models
The practical difference between the documented 25W and 30W options is not simply five watts. It is the combination of stated airflow, coverage, panel design, controls, and mounting conditions.
| Model | Airflow and coverage | Panel and exposure | Controls | Mounting |
|---|---|---|---|---|
| 25W roof mount | Up to 1,365 CFM; recommended for attics up to 1,300 square feet. | Fixed 25W panel; documented for smaller applications with south-facing roof exposure. | Automatic thermostat; no humidistat. | Roof mount; no electrical wiring required. |
| 30W roof mount | Up to 1,550 CFM; recommended for applications up to 1,500 square feet. | Adjustable panel for more flexible solar positioning. | Thermostat and humidistat; humidity activation is around 75% and deactivation around 60%. | Roof mount; current documentation identifies Florida and Texas windstorm certification, subject to project-specific verification. |
| 30W gable mount | Up to 1,550 CFM; recommended for applications around 1,500 square feet. | Gable placement can solve roof exposure or roof-layout constraints. | Verify current control details in the model documentation before quoting. | Gable mount; useful where roof penetration is undesirable or impractical. |
Choose the 25W roof mount when the attic fits its documented coverage, dependable exposure is available, and thermostat-only operation meets the project need. Its fixed panel and simpler control package can suit a straightforward smaller-attic installation.
Consider the 30W roof mount when the attic approaches 1,500 square feet, adjustable panel positioning is valuable, or humidity control matters. Select the 30W gable mount when the building layout favors a gable installation or a roof penetration is not practical. In each case, verify the current product documentation and the actual site conditions.
Review the documented solar attic fan models before you build a proposal around wattage alone.
How to Handle 40W and 60W Solar Attic Fan Requests
A responsible comparison must separate documented products from assumed specifications. The current The Attic Depot product documentation identifies 25W, 30W roof-mount, 30W gable-mount, and 70W roof-mount models. It does not verify 40W or 60W models or provide model-specific specifications for either rating.
Do not assign a 40W or 60W fan a CFM rating, coverage area, panel design, thermostat, humidistat, mounting method, certification, or dimension based only on the wattage. If a client, plan, or supplier request names one of those ratings, obtain the current manufacturer submittal before quoting, recommending, or substituting a product.
What to confirm before quoting an undocumented wattage
- Rated CFM and the test conditions behind that rating.
- Recommended attic coverage and any limits based on layout or ventilation.
- Panel adjustment, orientation requirements, and shading limitations.
- Thermostat, humidistat, or other operating controls.
- Roof-mount or gable-mount compatibility and installation requirements.
- Windstorm certification or other project-specific approvals.
- Whether the submittal applies to the exact model and current revision.
If the specification cannot be supported by current documentation, leave it out of the client-facing proposal rather than filling the gap with an estimate. Record attic square footage, roof orientation, shading, available mounting locations, intake ventilation, humidity concerns, and local requirements so the product request is specific and useful.
Why the Documented 70W Model Matters
The documented 70W roof-mount model is a verified high-capacity reference point for large attics or layouts where two 30W fans will not fit properly. It is rated up to 3,850 CFM and coverage up to 2,500 square feet. Those are documented application limits to evaluate against the actual attic design, not a guarantee that every installation will produce the same airflow.
A single higher-capacity unit may simplify a project when separate roof locations for two smaller fans would create clearance, framing, or installation problems. Still, confirm adequate intake ventilation, usable solar exposure, roof configuration, and the current model requirements before recommending it. Higher wattage does not resolve poor airflow planning or an attic that exceeds the documented coverage.
Review the 70W roof-mount product details as the model-specific reference. Treat it as a documented 70W option, not as evidence that an unverified 40W or 60W fan would deliver equivalent results.
How to Recommend the Right Wattage to a Client
1. Confirm the attic area. Measure or verify the space before selecting a model. Compare the result with documented coverage rather than estimating coverage from wattage. 2. Review the intake and exhaust plan. Confirm that intake ventilation is available and not blocked. Document the CFM and coverage basis for the proposed fan. 3. Check the sun and roof conditions. Evaluate orientation, shading, panel angle, and mounting space. A larger panel rating does not overcome poor exposure. 4. Choose roof or gable placement. Account for roof penetrations, roof geometry, framing, clearances, and the documented mounting method. 5. Match the controls. Decide whether the application needs a thermostat only or humidity response as well. Do not generalize one model's control package to another. 6. Verify project documents. Check the current submittal, installation requirements, certification documents, and any local approval requirements for the exact product.
Use this process to explain why a 25W model can be the correct fit for a smaller documented application, why a 30W model may add airflow, coverage, panel flexibility, or humidity control, and why a 70W model can serve a larger documented application. The recommendation should be based on the complete installation, not a wattage label by itself.
Become an authorized dealer for product documentation, technical support, training, and resources that help you make a defensible recommendation.
Frequently Asked Questions
Does higher wattage always mean more attic airflow?
No. Wattage describes rated electrical input capacity, not a standalone CFM or coverage guarantee. Compare the exact model's documented CFM, recommended attic area, solar exposure, ventilation balance, mounting conditions, and controls. See the documented solar attic fan specifications for model-level details.
How should I choose between a 25W and 30W solar attic fan?
Use the 25W roof-mount model when its documented rating of up to 1,365 CFM and coverage up to 1,300 square feet fit the application. Consider a documented 30W model for up to 1,550 CFM and applications around 1,500 square feet, or when adjustable panel positioning, humidity control, or gable mounting is important. Verify the site and current submittal before selecting the product.
Are 40W and 60W solar attic fans available?
The current product documentation does not verify 40W or 60W models or their specifications. Do not assign either rating a CFM, coverage area, control package, certification, or dimension from wattage alone. Obtain current manufacturer documentation before quoting or substituting either model.
When is a documented 70W model the better comparison point?
Use the documented 70W roof-mount model when the attic is large or the layout will not accommodate two 30W fans. Its published specifications describe up to 3,850 CFM and coverage up to 2,500 square feet. Confirm the roof configuration, ventilation plan, solar exposure, and model-specific installation requirements before final selection.
Support for Your Next Attic Ventilation Project
The right solar attic fan recommendation depends on the documented product, the building conditions, and the installation plan. The Attic Depot supports professional contractors with product education, technical guidance, training, and dealer resources. Become an authorized dealer to access contractor-focused support. For product, shipping, or technical questions, call 832-379-5757.
